Accurate and Reliable Measurement of Multiphase Flow
The DIP Multiphase Flow Meter utilizes advanced vibroacoustic technology to provide highly accurate measurements of multiphase flow.
Innovative Multiphase Flow Measurement
The DIP Multiphase Flow Meter (DIP MPFM) is engineered to deliver exceptional accuracy in gas, oil and water flow measurement across a variety of well types and production systems.
Whether it’s a naturally flowing well or a complex artificial lift, the DIP MPFM ensures real-time, reliable data, empowering you to optimize well management, reservoir performance, and overall production.
Real-Time
Highly Accurate
Cost Effective
Sustainable
The method of measurement is based on the analysis of vibroacoustic signals generated by the fluid flowing through the choke.
Due to the multiphase composition of the fluid, it flows turbulently, causing uneven speeds inside and outside of the vortices, which leads to local pressure drops. These fluctuations in pressure make the pipe vibrate at its resonant frequency. The intensity and distribution of such oscillations are used as the primary source of information.
The vibroacoustic signal is measured by an accelerometer and, after filtering, is converted into flow rate, GVF, water cut and fluid density. Measured differential pressure is used to calculate the mass flow rate and the velocity.
